0.6/1 kV及以下交联聚乙烯绝缘电力电缆
含普通型、阻燃型(阻燃电缆)、耐火型(耐火电缆) 0.6/1 kV AND BELOW XLPE INSULATED POWER CABLE (Including the common types, flame retardant types, fire-resistant types) 一、产品特点及用途 Features and uses 交联聚乙烯绝缘电力电力,具有高机械强度、耐环境应力好、优良的电气性能和耐化学腐蚀等特点,产品重量轻,结构简单,使用方便。本产品适用于额定电压0.6/1 kV输配电系统,供输配电能之用。 阻燃型电缆的主要特点是电缆不易着火,或着火时延燃仅局限在一定范围内,适用于电缆敷设密集程度比较高的发电站、地铁、隧道、高层建筑、大兴工矿企业、油田、煤矿等场所。 耐火型电缆的主要特点是除了能在正常的工作条件下传输电力外,电缆在着火燃烧时仍能保持一定时间的正常运行。适用于核电站、地铁、隧道、高层建筑等与防火安全和消防救生有关的场所。 XLPE insulated power cables, which has high mechanical robustness, good environmental stress, excellent electrical properties and chemical resistance characteristics, is simple in structure ,light in weight and convenient in applicable. This product is suitable for rated voltage of 0.6/1 kV power distribution system, for transmission and distribution of electric energy use. The main features of flame retardant cable is not easy to catch fire,or it can confine the fire in some limited area. There fore the cable is applicable to the places where the density of cable laying is high,such as generating stations, subways, tunnels, high-rise buildings, large industrial and mining enterprises, oil field, coal mine and other places. The fire-resistant cable is besides the power transmission under normal condition, can continue operating normally for some time when it catches fire,so it is applicable to the place which is concerned to the fires safety and fire rescue,such as nuclear power plant,subway,tunnel,high-rise building and so on. 二、执行标准 Standards GB12706或IEC 60502及相关的国内外标准。如:BS、VDE、JIS、AEIC等。 IEC60502 and GB12706 or the relevant domestic and international standards. Such as: BS, VDE, JIS, AEIC and so on. 三、使用特性 Product features 1、电缆导体最高允许工作温度:正常运行时90 ℃,短路时(****短路持续时间5 s)为250 ℃。 Max. admissible temperature for conductor:90 ℃ under normal running condition,250 ℃ during short circuit(max. duration not exceeding 5s). 2、电缆的敷设****温度为0℃,敷设时最小弯曲半径为: 单芯电缆20(D+d)±5 %,mm 多芯电缆15(D+d)±5 %,mm 式中:D--电缆的实际外径,mm d--电缆导体的实际外径,mm Minimum temperature of the cable laying 0 ℃, the minimum bending radius when laid: Single-core cable: 20 (D + d) ± 5%, mm Multi-core cable:15 (D + d) ± 5%, mm Where:D--Cable diameter mm of the actual d--mm diameter cable conductor of the actual 四、产品型号及名称(见表4-1) Types of products(Table 4-1)
表4-1 Table 4-1
五、0.6/1 kV交联电缆结构示意图 0.6/1 kV XLPE cable schematic 0.6/1 kV交联电缆结构包括单芯结构、二芯结构、三芯结构、四芯结构(含3+1结构)、五芯结构(含4+1,3+2结构)等,分别见图1-13。 0.6/1 kV XLPE cable structure comprises a single core, two core, three core, four core (including 3+1 structure ), five core structure(including 4+1,3+2 ), respectively, as shown in Figure 1-13。
六、产品的结构参数 Product structure parameters 0.6/1 kV交联电缆主要结构参数包括单芯电缆、二芯电缆、三芯电缆、四芯电缆(含3+1芯电缆)、五芯电缆(含4+1芯电缆,3+2芯电缆)等,分别见表6-1~6-8。 0.6 / 1 kV XLPE cable main structure parameters including single core cable, two core cable, three core cable, four core cable(including 3+1 core cable),five core cable(including 4+1 core cable, 3+2 core cable), respectively, are shown in table 6-1 to 6-8. 1、单芯电缆 Single core cable 表6-1单芯非铠装电缆 Table 6-1Single core unarmored cable
芯数×截面
Nominal section
( mm2) |
绝缘标称厚度
Insulation nominal
thickness (mm) |
外护套标称厚度
Outer sheath
thickness (mm) |
电缆近似外径 Approximate
outer diameter (mm) |
电缆近似重量
Cable apptox weight (kg/km) |
铜芯 Copper core |
铝芯 Aluminum |
1×2.5
1×4
1×6
1×10
1×16 |
0.7
0.7
0.7
0.7
0.7 |
1.8
1.8
1.8
1.8
1.8 |
6.6
7.1
7.6
8.9
9.9 |
60
77
99
148
208 |
—
—
—
88
114 |
1×25
1×35
1×50
1×70
1×95 |
0.9
0.9
0.9
1.1
1.1 |
1.8
1.8
1.8
1.8
1.8 |
11.6
12.8
14.2
16.4
18.4 |
312
412
543
757
1011 |
159
198
257
344
438 |
1×120
1×150
1×185
1×240
1×300 |
1.2
1.4
1.6
1.7
1.8 |
1.8
1.8
1.8
1.8
1.9 |
20.4
22.3
24.8
27.7
30.6 |
1267
1534
1920
2484
3090 |
541
657
806
1015
1240 |
1×400
1×500
1×630
1×800
1×1000 |
2.0
2.2
2.4
2.6
2.8 |
1.9
2.1
2.2
2.4
2.6 |
34.1
38.1
42.3
47.2
50.9 |
3949
5041
6390
8135
10013 |
1599
1969
2437
3040
3723 |
表6-2 单芯铠装电缆 Table 6-1 Single core armored cable
芯数×截面
Nominal section
( mm2) |
绝缘
标称厚度
Insulation nominal
thickness (mm) |
外护套标
称厚度
Outer sheath thickness
(mm) |
电缆近似外径 Approximate
outer diameter
(mm) |
电缆近似重量
Cable apptox weight (kg/km) |
铜芯 Copper core |
铝芯 Aluminum |
1×2.5
1×4
1×6
1×10
1×16 |
0.7
0.7 |
1.8
1.8 |
—
—
—
12.5
13.5 |
—
—
—
300
376 |
—
—
—
240
282 |
1×25
1×35
1×50
1×70
1×95 |
0.9
0.9
1.0
1.1
1.1 |
1.8
1.8
1.8
1.8
1.8 |
15.2
16.4
17.8
19.8
22.1 |
497
614
766
1003
1301 |
344
399
481
588
725 |
续表6-2 Continued table 6-2
芯数×截面
Nominal section
( mm2) |
绝缘
标称厚度
Insulation nominal
thickness (mm) |
外护套标
称厚度
Outer sheath thickness
(mm) |
电缆近似外径 Approximate
outer diameter (mm) |
电缆近似重量
Cable apptox weight (kg/km) |
铜芯 Copper core |
铝芯 Aluminum |
1×120
1×150
1×185
1×240
1×300 |
1.2
1.4
1.6
1.7
1.8 |
1.8
1.8
1.9
2.0
2.1 |
23.9
26.0
28.5
31.4
34.3 |
1575
1883
2308
2917
3568 |
846
1002
1186
1439
1705 |
1×400
1×500
1×630
1×800
1×1000 |
2.0
2.2
2.4
2.6
2.8 |
2.0
2.2
2.4
2.6
2.8 |
39.2
43.4
47.8
52.7
56.2 |
4923
6150
7646
9542
11508 |
2559
3050
3657
4403
5156 |
2、二芯电缆见表6-3 Two core cable in table 6-3 注:铁磁性铠装单芯及二芯电缆若用于交流系统,需有有效降低磁效应的措施,否则只可于直流系统。 Note: ferromagnetic armoured single core or two core cable. If used for AC system, has effectively reduce the magnetic effect measures, otherwise only in DC system. 表6-3 Table 6-3
芯数×截面
Nominal section
( mm2) |
绝缘
标称厚度
Insulation nominal
thickness (mm) |
外护套
标称厚度
Outer sheath thickness (mm) |
电缆近似外径 Approximate
outer diameter (mm) |
电缆近似重量
Cable apptox weight (kg/km) |
铜芯 Copper core |
铝芯 Aluminum |
非铠装
unarmored |
铠装
armored |
非铠装
unarmored |
铠装
armored |
YJV |
YJV22 |
YJLV |
YJLV22 |
2×2.5
2×4
2×6
2×10
2×16 |
0.7
0.7
0.7
0.7
0.7 |
1.8
1.8
1.8
1.8
1.8 |
—
1.8
1.8
1.8
1.8 |
10.5
11.4
12.4
15.0
17.1 |
—
14.0
15.0
17.6
19.6 |
123
169
218
328
461 |
—
303
364
497
655 |
—
—
149
209
274 |
—
—
296
378
468 |
2×25
2×35
2×50
2×70
2×95 |
0.9
0.9
1
1.1
1.1 |
1.8
1.8
1.8
1.9
2.1 |
1.8
1.8
1.9
2.1
2.2 |
20.5
22.8
25.7
29.9
33.9 |
23.1
25.4
28.9
33.1
37.0 |
693
911
1200
1666
2227 |
928
1175
1538
2065
2681 |
388
485
632
844
1087 |
623
747
970
1240
1535 |
2×120
2×150
2×185
2×240
2×300 |
1.2
1.4
1.6
1.7
1.8 |
2.2
2.3
2.4
2.5
2.7 |
2.3
2.5
2.6
2.8
3.0 |
37.6
41.5
46.6
52.1
57.8 |
42.0
46.1
51.8
57.4
63.1 |
2796
3409
4279
5512
6859 |
3740.
4471
5562
6948
8458 |
1351
1664
2059
2590
3175 |
2291
2723
3333
4016
4754 |
2×400
2×500
2×630 |
2.0
2.2
2.4 |
2.9
3.1
3.4 |
3.2
3.3
3.6 |
64.8
72.6
80.8 |
71.5
79.4
87.6 |
8753
11145
14090 |
11379
14130
17423 |
4070
5007
6190 |
6674
7939
9453 |
3、三芯电缆见表6-4 Three core cable in table 6-4 表6-4 Table 6-4
芯数×截面
Nominal section
( mm2) |
绝缘
标称厚度
Insulation nominal
thickness (mm) |
外护套
标称厚度
Outer sheath
thickness (mm) |
电缆近似外径 Approximate
outer diameter (mm) |
电缆近似重量
Cable apptox weight (kg/km) |
铜芯 Copper core |
铝芯 Aluminum |
非铠装
unarmored |
铠装
armored |
非铠装
unarmored |
铠装
armored |
YJV |
YJV22 |
YJLV |
YJLV22 |
3×4
3×6
3×10
3×16
3×25
3×35 |
0.7
0.7
0.7
0.7
0.9
0.9 |
1.8
1.8
1.8
1.8
1.8
1.8 |
1.8
1.8
1.8
1.8
1.8
1.8 |
12.0
13.1
15.9
18.1
21.8
24.3 |
14.5
15.6
18.4
20.6
24.3
26.8 |
223
297
446
638
959
1275 |
365
452
637
858
1211
1559 |
—
—
266
355
500
633 |
—
—
457
575
750
913 |
3×50
3×70
3×95
3×120
3×150
3×185 |
1.0
1.1
1.1
1.2
1.4
1.6 |
1.8
1.9
2.0
2.1
2.3
2.4 |
1.9
2.1
2.2
2.3
2.4
2.6 |
23.5
26.8
32.1
34.1
38.9
42.3 |
26.6
30.0
36.4
38.4
44.4
47.5 |
1570
2184
2966
3654
4584
5673 |
1884
2547
3782
4514
5693
6850 |
744
1003
1286
1592
1954
2426 |
1097
1419
2186
2578
3182
3763 |
3×240
3×300
3×400
3×500
3×630 |
1.7
1.8
2.0
2.2
2.4 |
2.6
2.8
3.1
3.3
3.6 |
2.8
3.0
3.3
3.5
3.9 |
47.7
52.2
68.5
76.1
84.9 |
52.9
57.3
75.0
82.4
91.4 |
7385
9216
12137
15151
19146 |
8722
10658
14893
18198
22603 |
3048
3786
4875
5856
7263 |
4557
5420
7585
8818
10610 |
4、四芯电缆见表6-5~6-6 Fore core cable in table 6-5~6-6 表6-5 四等芯电缆 Table 6-5 Four core cable
芯数×截面
Nominal section
( mm2) |
绝缘标
厚度
Insulation nominal
thickness (mm) |
外护套
标称厚度
Outer sheath
thickness (mm) |
电缆
近似外径 Approximate
outer diameter (mm) |
电缆近似重量
Cable apptox weight (kg/km) |
铜芯 Copper core |
铝芯 Aluminum |
非铠装
unarmored |
铠装
armored |
非铠装
unarmored |
铠装
armored |
YJV |
YJV22 |
YJLV |
YJLV22 |
4×4
4×6
4×10
4×16
4×25 |
0.7
0.7
0.7
0.7
0.9 |
1.8
1.8
1.8
1.8
1.8 |
1.8
1.8
1.8
1.8
1.8 |
18.1
19.5
22.5
25.1
29.2 |
14.6
15.9
18.9
21.5
25.6 |
534
644
900
1186
1656 |
436
494
644
783
1029 |
284
372
645
819
122 |
185
222
390
416
593 |
4×35
4×50
4×70
4×95
4×120
4×150 |
0.9
1.0
1.1
1.1
1.2
1.4 |
1.8
1.9
2.0
2.1
2.3
2.4 |
1.9
2.0
2.2
2.3
2.4
2.6 |
26.7
28.0
33.2
38.0
40.9
46.0 |
29.4
32.6
37.5
42.6
46.4
51.3 |
1631
2080
2952
3970
4894
6069 |
1957
2812
3796
4962
6060
7349 |
776
961
1302
1693
2077
2582 |
1096
1770
2222
2757
3363
39755 |
4×185
4×240
4×300
4×400
4×500
4×630 |
1.6
1.7
1.8
2.0
2.2
2.4 |
2.6
2.8
3.0
3.3
3.6
3.9 |
2.8
3.0
3.2
3.6
3.9
4.2 |
52.5
59.4
66.2
73.8
89.3
99.6 |
57.8
64.6
71.6
80.3
96.0
106.3 |
7553
9910
12303
15858
20174
25500 |
9021
11571
14202
18867
23845
29617 |
3173
4032
4924
6366
7781
9656 |
4732
5782
6903
9546
11338
1362 |
表6-6 3+1芯电缆 Table 6-6 3+1core cable
芯数×截面
Nominal section
( mm2) |
绝缘标
称厚度
Insulation nominal
thickness (mm) |
外护套
标称厚度
Outer sheath
thickness (mm) |
电缆近似外径 Approximate outer
diameter (mm) |
电缆近似重量
Cable apptox weight (kg/km) |
铜芯 Copper core |
铝芯 Aluminum |
非铠装
unarmored |
铠装
armored |
非铠装
unarmored |
铠装
armored |
YJV |
YJV22 |
YJLV |
YJLV22 |
3×4+2.5
3×6+4
3×10+6
3×16+10
3×25+16 |
0.7
0.7
0.7
0.7
0.9 |
1.8
1.8
1.8
1.8
1.8 |
1.8
1.8
1.8
1.8
1.8 |
12.7
13.8
16.5
19.2
22.9 |
15.2
16.4
19.1
21.7
25.4 |
258
346
521
761
1150 |
399
502
709
981
1417 |
—
—
305
417
596 |
—
—
493
637
860 |
3×35+16
3×50+25
3×70+35
3×95+50
3×120+70
3×150+70 |
0.9
1.0
1.1
1.1
1.2
1.4 |
1.8
1.8
1.9
2.1
2.2
2.3 |
1.8
2.0
2.1
2.2
2.4
2.5 |
25.0
26.4
30.7
35.2
38.5
42.4 |
27.5
29.5
35.1
39.5
42.9
47.6 |
1435
1868
2592
3513
4456
5304 |
1729
2223
3376
4409
5435
6486 |
699
839
1125
1475
1832
2196 |
988
1185
1896
2354
2788
3350 |
3×185+95
3×240+120
3×300+150
3×400+185
3×500+240
3×630+300 |
1.6
1.7
1.8
2.0
2.2
2.4 |
2.5
2.7
2.9
3.2
3.4
3.7 |
2.7
2.9
3.1
3.4
3.6
3.9 |
48.2
54.3
60.5
69.7
80.7
90.5 |
53.6
59.6
65.7
74.9
86.0
95.8 |
6711
8699
10727
14398
17526
22050 |
8076
10221
12422
16373
19824
25670 |
, 2729
3471
4270
5488
6958
8970 |
4057
4945
5906
7336
9560
11450 |
5、五芯结构电缆见表6-7~6-9 Five core cable in table 6-7~6-9 表6-7 五等芯电缆 Table 6-7 Five core cable
芯数×截面
Nominal section
( mm2) |
绝缘标
称厚度
Insulation nominal thickness
(mm) |
外护套
标称厚度
Outer sheath
thickness (mm) |
电缆近似外径 Approximate
outer diameter (mm) |
电缆近似重量
Cable apptox weight (kg/km) |
铜芯 Copper core |
铝芯 Aluminum |
非铠装
unarmored |
铠装
armored |
非铠装
unarmored |
铠装
armored |
YJV |
YJV22 |
YJLV |
YJLV22 |
5×4
5×6
5×10
5×16
5×25 |
0.7
0.7
0.7
0.7
0.9 |
1.8
1.8
1.8
1.8
1.8 |
1.8
1.8
1.8
1.8
2.0 |
14.0
15.3
18.9
21.6
26.3 |
16.6
17.9
21.4
24.2
29.2 |
337
453
692
997
1522 |
494
626
908
1249
1856 |
—
—
391
525
756 |
—
—
607
775
1087 |
5×35
5×50
5×70
5×95
5×120 |
0.9
1.0
1.1
1.1
1.2 |
1.9
2.1
2.3
2.5
2.6 |
2.1
2.2
2.4
2.6
2.8 |
29.5
31.7
37.2
42.7
47.1 |
32.7
36.2
41.7
48.1
52.5 |
2032
2664
2722
5000
6253 |
2430
3366
4692
6220
7584 |
1307
1741
2230
2745
962 |
1353
1998
2694
3426
4044 |
5×150
5×185
5×240
5×300 |
1.4
1.6
1.7
1.8 |
2.8
3.0
3.1
3.3 |
3.0
3.2
3.3
3.5 |
51.9
58.9
66.6
72.9 |
57.1
64.2
71.8
79.4 |
7684
9535
12416
15268 |
9136
11179
14292
18226 |
3382
4182
5259
6318 |
4796
5777
7069
9194 |
表6-8 4+1芯电缆 Table 6-8 4+1core cable
芯数×截面
Nominal section
( mm2) |
绝缘标
称厚度
Insulation nomina
l thickness (mm) |
外护套
标称厚度
Outer sheath t
hickness (mm) |
电缆近似外径 Approximat
e outer diameter (mm) |
电缆近似重量
Cable apptox weight (kg/km) |
铜芯 Copper core |
铝芯 Aluminum |
非铠装
unarmored |
铠装
armored |
非铠装
unarmored |
铠装
armored |
YJV |
YJV22 |
YJLV |
YJLV22 |
4×4+2.5
4×6+4
4×10+6
4×16+10
4×25+16 |
0.7
0.7
0.7
0.7
0.9 |
1.8
1.8
1.8
1.8
1.8 |
1.8
1.8
1.8
1.8
1.9 |
13.7
15.1
18.2
21.1
25.3 |
16.3
17.6
20.7
23.6
27.9 |
323
427
652
934
1410 |
477
598
860
1178
1708 |
232
282
404
514
756 |
387
451
612
748
1051 |
4×35+16
4×50+25
4×70+35
4×95+50
4×110+70
4×150+70 |
0.9
1.0
1.1
1.1
1.2
1.4 |
1.9
2.1
2.2
2.4
2.5
2.7 |
1.9
2.1
2.3
2.4
2.6
2.7 |
27.8
30.1
35.2
40.2
44.7
48.6 |
30.5
34.6
39.5
44.8
50.2
53.8 |
1805
2358
3317
4467
5658
6828 |
2146
3145
4214
5520
6934
8183 |
915
1128
1526
1976
2453
2973 |
1250
1904
2407
3006
3700
4292 |
4×185+95
4×240+120
4×300+150
4×400+185
4×500+240
4×630+300 |
1.6
1.7
1.8
2.0
2.2
2.4 |
2.9
3.0
3.2
3.5
3.7
4.0 |
2.9
3.1
3.4
3.8
3.9
4.3 |
55.3
62.5
69.5
77.2
91.7
102.5 |
60.6
67.7
74.9
83.8
98.2
109.8 |
8532
11152
13860
17649
22879
29540 |
10082
12906
15863
20816
26613
32680 |
3696
4707
5789
7406
9351
12680 |
5200
6400
7716
10477
12959
16530 |
表6-9 3+2 芯电缆 Table 6-9 3+2 core cable
芯数×截面
Nominal section
( mm2) |
绝缘标
称厚度
Insulation nominal
thickness (mm) |
外护套标称厚度
Outer sheath thicknes
s (mm) |
电缆近似外径 Approximat
e outer diameter (mm) |
电缆近似重量
Cable apptox weight (kg/km) |
铜芯 Copper core |
铝芯 Aluminum |
非铠装
unarmored |
铠装
armored |
非铠装
unarmored |
铠装
armored |
YJV |
YJV22 |
YJLV |
YJLV22 |
3×4+2×2.5
3×6+2×4
, 3×10+2×6
3×16+2×10
3×25+2×16 |
0.7
0.7
0.7
0.7
0.9 |
1.8
1.8
1.8
1.8
1.8 |
1.8
1.8
1.8
1.8
1.8 |
13.5
14.8
17.4
20.5
24.4 |
16.1
17.4
20.0
23.1
27.1 |
307
407
599
880
1306 |
458
574
799
1117
1602 |
208
254
349
476
658 |
359
422
548
712
950 |
3×35+2×16
3×50+2×25
3×70+2×35
3×95+2×50
3×120+2×70
3×150+2×70 |
0.9
1.0
1.1
1.1
1.2
1.4 |
1.8
1.9
2.1
2.2
2.4
2.5 |
1.9
2.0
2.2
2.4
2.5
2.6 |
26.3
29.1
33.7
38.7
43.4
46.2 |
29.2
33.7
38.2
43.2
48.9
51.7 |
1601
2158
2989
4040
5192
6057 |
1936
2919
3866
5049
6429
7369 |
770
990
1308
1730
2169
2523 |
1101
1742
2171
2722
3382
3805 |
3×185+2×95
3×240+2×120
3×300+2×150
3×400+2×185
3×500+2×240
3×630+2×300 |
1.6
1.7
1.8
2.0
2.2
2.4 |
2.6
2.8
3.0
3.3
3.6
3.8 |
2.8
3.0
3.2
3.5
3.8
4.1 |
52.5
59.1
65.8
73.2
92.8
102.6 |
58.1
64.6
71.2
78.6
99.4
109.8 |
7625
9909
12278
15648
23100
24690 |
9142
11606
14156
17761
26895
29860 |
3118
3969
4889
6223
7890
10520 |
4597
5614
6703
8250
10630
12850
| , >2.1 |
23.9
26.0
28.5
31.4
34.3 |
1575
1883
2308
2917
3568 |
846
1002
1186
1439
1705 |
